0i - PC Connection manual (Function) Page 144

Connection manual (Function)
B. ALARM LIST
B–64153EN/01
APPENDIX
132
Number ContentsMessage
4831 ZONE : ENTERING INHIBITED 1
–Y
When a safety zone check was executed, the machine moving in the
negative Y direction entered area 1 into which entry is inhibited.
4832 ZONE : ENTERING INHIBITED 2 +Y When a safety zone check was executed, the machine moving in the
positive Y direction entered area 2 into which entry is inhibited.
4833 ZONE : ENTERING INHIBITED 2
–Y
When a safety zone check was executed, the machine moving in the
negative Y direction entered area 2 into which entry is inhibited.
4834 ZONE : ENTERING INHIBITED 3 +Y When a safety zone check was executed, the machine moving in the
positive Y direction entered area 3 into which entry is inhibited.
4835 ZONE : ENTERING INHIBITED 3
–Y
When a safety zone check was executed, the machine moving in the
negative Y direction entered area 3 into which entry is inhibited.
4836 ZONE : ENTERING INHIBITED 4 +Y When a safety zone check was executed, the machine moving in the
positive Y direction entered area 4 into which entry is inhibited.
4837 ZONE : ENTERING INHIBITED 4
–Y
When a safety zone check was executed, the machine moving in the
negative Y direction entered area 4 into which entry is inhibited.
4870 AUTO SETTING FEED ERROR The feed rate of safety zone auto setting is other than the parameter
value (No. 16538, No. 16539).
4871 AUTO SETTING PIECES ERROR In safety zone auto setting, the safety zone pieces are not correct. Or
the position detector has gone wrong, please tell your machine tool
builder.
4872 AUTO SETTING COMMAND ER-
ROR
M code, S code or T code is specified with safety zone auto setting
command (G32).
G32 is specified in the nibbling mode, in the cutter compensation, in
the rotation mode or the scaling mode.
