0i - PC Connection manual (Function) Page 135

Connection manual (Function)
B–64153EN/01
A. CNC AND PMC INTERFACEAPPENDIX
123
Function Name Symbol Address Item
External operation function External operation function select signal EFS G230#7 3.7
Tool life management Tool expired signal PTLCH F232#0 2.9.2
C–axis offset
Coupling enable signal CPEN F232#4 6.3.2
C–axis unconnected signal CFDC G233#7 6.3.2
Feed hold signal B Feed hold signal B *SPR X008#5 8.1
Feed hold lamp signal B Feed hold lamp signal B SPRL F230#4 8.1
Manual tool change
Manual tool change signal MNTCHG G240#3 5.5
Manual tool change in–progress signal MNTNOD F233#3 5.5
Skip function Skip signal SKIP X004#0 2.11.1
Safety zone check
Punch enable signal WDC G232#4 7.2
Punch forbidden area entered signal WDDO F231#7 7.2
Safety zone setting ready signal SAFEXE F231#6 7.2
Workpiece holder position detector
signal
SAFZ X004#1 7.5
Selection signal for tool area of safety
zone
SZTS0–SZTS3 G232#0–#3 7.6
In safety zone signal SZT1–SZT12 F240–F241#0–#3 7.6
Automatic safety zone setting request
signal
SAFRQ G232#5 7.5.2
Soft thermal monitor function
Soft thermal monitor axis selection sig-
nals
OVAX0–OVAX3 G247#0–#3 8.4
Soft thermal monitor signals OVC0–OVC6 F243#0–#6 8.4
Multi–piece machining function Multi–piece machining setting signal MLP1,MLP2 G231#0,#1 4.2
Turret axis control (T axis control)
T command neglect signal TNG G233#5 5.3.1
Tool change signal TCNG G233#6 5.3.2
Turret indexing completion signal TIE F236#6 5.3.3
T code display signal TI00–TI31 G234–G237 5.3.4
Number of punches signal PN00–PN31 F234–F237 5.3.5
T–axis machine zero point position
signals
RP1T–RP16T F244–F245 5.3.6
Unregistered T code signal Unregistered T code signal NRTCD F242#0 5.4
A.2
LIST OF SIGNALS
A.2.1
List of Signals in the
Order of Functions
Previous page
Next page
