0i - PC Connection manual (Function) Page 15

Connection manual (Function)
B–64153EN/01
1. LIST OF FUNCTIONS
3
No.
Whether
supported
Item
3.1 Jog feed/incremental feed f
3.2 Manual handle feed f
3.3 Manual handle interruption f
4 Reference position establishment
4.1 Manual reference position return f
4.2 Setting the reference position without DOG f
4.3 Reference position shift f
4.4 Reference position return ∆: See chapter 2
4.5 2nd reference position return/3rd, 4th
reference position return
∆: See chapter 2
4.6 Reference position setting with mechanical
stopper
×
4.7 Linear scale with absolute addressing
reference marks
f
4.8 Linear scale with absolute address reference
mark expansion
×
5 Automatic operation
5.1 Cycle start/feed hold ∆: See chapter 2
5.2 Reset and rewind f
5.3 Testing a program
Machine lock ∆: See chapter 2
Dry run f
Single block ∆: See chapter 2
5.4 Manual absolute on/off ∆: ”Manual
absolute off” is
unavailable.
5.5 Addition of optional block skip f
5.6 Sequence number comparison and stop f
5.7 Program restart ×
5.8
Exact stop/exact stop mode/cutting mode f
Tapping mode ×
5.9 DNC operation f
5.10 Manual intervention and return ×
5.11 Retraction for rigid tapping ×
6 Interpolation function
6.1 Positioning ∆: See chapter 2
