Series 16i/18i/160i/180i - PA Operators manual Page 486

Operators manual
OPERATION
8. DATA INPUT/OUTPUT
B–63124EN/01
476
Parameters and pitch error compensation data are input and output from
different screens, respectively. This chapter describes how to enter them.
Parameters are loaded into the memory of the CNC unit from a floppy or
NC tape. The input format is the same as the output format. See Section
8.6.2. When a parameter is loaded which has the same data number as a
parameter already registered in the memory, the loaded parameter
replaces the existing parameter.
Inputting parameters
1 Make sure the input device is ready for reading.
2 When using a floppy, search for the required file according to the
procedure in Section
8.2.
3 Press the EMERGENCY STOP button on the machine operator’s
panel.
4 Press function key
OFFSET
SETTING
.
5 Press the soft key
[SETING] for chapter selection.
6 Enter 1 in response to the prompt for writing parameters (PWE).
Alarm P/S100 (indicating that parameters can be written) appears.
7 Press soft key
SYSTEM
.
8 Press chapter selection soft key
[PARAM].
9 Press soft key
[(OPRT)].
10 Press the rightmost soft key
(next–menu key).
11 Press soft keys
[READ] and [EXEC].
Parameters are read into memory. Upon completion of input, the
”INPUT” indicator at the lower–right corner of the screen disappears.
12 Press function key
OFFSET
SETTING
.
13 Press soft key
[SETING] for chapter selection.
14 Enter 0 in response to the prompt for writing parameters.
15 Turn the power to the NC back on.
16 Release the EMERGENCY STOP button on the machine operator’s
panel.
8.6
INPUTTING AND
OUTPUTTING
PARAMETERS AND
PITCH ERROR
COMPENSATION
DATA
8.6.1
Inputting Parameters

