Series 16i/18i/160i/180i - PA Operators manual Page 703

Operators manual
APPENDIX
G. ALARM LIST
B–63124EN/01
696
Number ContentsMessage
118 PARENTHESIS NESTING ERROR The nesting of bracket exceeds the upper limit (quintuple).
Modify the program.
119 ILLEGAL ARGUMENT The SQRT argument is negative, BCD argument is negative, or other
values than 0 to 9 are present on each line of BIN argument.
Modify the program.
122 DUPLICATE MACRO MODAL–CALL The macro modal call is specified in double.
Modify the program.
123 CAN NOT USE MACRO COMMAND
IN DNC
Macro control command is used during DNC operation.
Modify the program.
124 MISSING END STATEMENT DO – END does not correspond to 1 : 1. Modify the program.
125 FORMAT ERROR IN MACRO <Formula> format is erroneous. Modify the program.
126 ILLEGAL LOOP NUMBER In DOn, 1x n x3 is not established. Modify the program.
127 NC, MACRO STATEMENT IN SAME
BLOCK
NC and custom macro commands coexist.
Modify the program.
128 ILLEGAL MACRO SEQUENCE NUM-
BER
The sequence number specified in the branch command was not 0 to
9999. Or, it cannot be searched. Modify the program.
129 ILLEGAL ARGUMENT ADDRESS An address which is not allowed in <Argument Designation > is used.
Modify the program.
130 ILLEGAL AXIS OPERATION An axis control command was given by PMC to an axis controlled by
CNC. Or an axis control command was given by CNC to an axis con-
trolled by PMC. Modify the program.
131 TOO MANY EXTERNAL ALARM
MESSAGES
Five or more alarms have generated in external alarm message.
Consult the PMC ladder diagram to find the cause.
132 ALARM NUMBER NOT FOUND No alarm No. concerned exists in external alarm message clear.
Check the PMC ladder diagram.
133 ILLEGAL DATA IN EXT. ALARM MSG Small section data is erroneous in external alarm message or external
operator message. Check the PMC ladder diagram.
138 SUPERIMPOSED DATA OVER-
FLOW
The total distribution amount of the CNC and PMC is too large during
superimposed control of the extended functions for PMC axis control.
139 CAN NOT CHANGE PMC CONTROL
AXIS
An axis is selected in commanding by PMC axis control.
Modify the program.
141 CAN NOT COMMAND G51 IN CRC G51 (Scaling ON) is commanded in the tool offset mode.
Modify the program.
142 ILLEGAL SCALE RATE Scaling magnification is commanded in other than 1 – 999999.
Correct the scaling magnification setting (G51 Pp or parameter
. .
5411 or 5421).
143 SCALED MOTION DATA OVER-
FLOW
The scaling results, move distance, coordinate value and circular radius
exceed the maximum command value. Correct the program or scaling
mangification.
144 ILLEGAL PLANE SELECTED The coordinate rotation plane and arc or cutter compensation C plane
must be the same. Modify the program.
148 ILLEGAL SETTING DATA Automatic corner override deceleration rate is out of the settable range
of judgement angle. Modify the parameters (No.1710 to No.1714)
179 PARAM. (NO. 7510) SETTING ER-
ROR
The number of controlled axes set by the parameter 7510 exceeds the
maximum number. Modify the parameter setting value.
180 COMMUNICATION ERROR
(REMOTE BUF)
Remote buffer connection alarm has generated. Confirm the number of
cables, parameters and I/O device.
199 MACRO WORD UNDEFINED Undefined macro word was used. Modify the custom macro.
210 CAN NOT COMMAND M198/M199 M198 and M199 are executed in the schedule operation. Or M198 is
executed in the DNC operation.
