G. ALARM LIST
B–63124EN/01
706
#7
ALD201
#6 #5 #4
EXP
#3 #2 #1 #0
When OVL equal 1 in diagnostic data No.200 (servo alarm No. 400 is
being generated):
#7 (ALD) 0 : Motor overheating
1 : Amplifier overheating
When FBAL equal 1 in diagnostic data No.200 (servo alarm No. 416 is
being generated):
ALD EXP Alarm details
1 0 Built–in pulse coder disconnection (hardware)
1 1 Separately installed pulse coder disconnection
(hardware)
0 0 Pulse coder is not connected due to software.
#7
204
#6
OFS
#5
MCC
#4
LDA
#3
PMS
#2 #1 #0
#6 (OFS) : A current conversion error has occured in the digital servo.
#5 (MCC) : A magnetic contactor contact in the servo amplifier has welded.
#4 (LDA) : The LED indicates that serial pulse coder C is defective
#3 (PMS) : A feedback pulse error has occured because the feedback cable is
defective.
10) Over travel alarms
Number Message Contents
500 OVER TRAVEL : +n Exceeded the n–th axis (axis 1 to 8) + side stored stroke limit I.
(Parameter No.1320 or 1326 Notes)
501 OVER TRAVEL : –n Exceeded the n–th axis (axis 1 to 8) – side stored stroke limit I.
(Parameter No.1321 or 1327 Notes)
502 OVER TRAVEL : +n Exceeded the n–th axis (axis 1 to 8) + side stored stroke limit II.
(Parameter No.1322 )
503 OVER TRAVEL : –n Exceeded the n–th axis (axis 1 to 8) – side stored stroke limit II.
(Parameter No.1323)
506 OVER TRAVEL : +n Exceeded the n–th axis (axis 1 to 8) + side hardware OT.
507 OVER TRAVEL : –n Exceeded the n–th axis (axis 1 to 8) – side hardware OT.
11) Overheat alarms
Number Message Contents
700 OVERHEAT: CONTROL UNIT Control unit overheat.
Check that the fan motor operates normally, and clean the air filter.
701 OVERHEAT: FAN MOTOR The fan motor on the top of the cabinet for the contorl unit is overheated.
Check the operation of the fan motor and replace the motor if necessary.
704 OVERHEAT: SPINDLE Spindle overheat in the spindle fluctuation detection.
(1)If the cutting load is heavy, relieve the cutting condition.
(2)Check whether the cutting tool is share.
(3)Another posible cause is a faulty spindle amp.
