APPENDIX

E. STATUS WHEN TURNING POWER ON,

WHEN CLEAR AND WHEN RESET

B–63124EN/01

690

STATUS WHEN TURNING POWER ON, WHEN CLEAR

AND WHEN RESET

Parameter 3402 (CLR) is used to select whether resetting the CNC places

it in the cleared state or in the reset state (0: reset state/1: cleared state).

The symbols in the tables below mean the following :

f:The status is not changed or the movement is continued.

×:The status is cancelled or the movement is interrupted.

Item When turning power on Cleared Reset

Setting

data

Offset value f f f

Data set by the MDI

setting operation

f f f

Parameter f f f

Various

data

Programs in memory f f f

Contents in the buffer

storage

× × f : MDI mode

× : Other mode

Display of sequence

number

f f (Note 1) f (Note 1)

One shot G code × × ×

Modal G code Initial G codes.

(The G20 and G21 codes

return to the same state

they were in when the

power was last turned off.)

Initial G codes.

(G20/G21 are not

changed.)

F Zero Zero f

S, T, M × f f

K (Number of repeats) × × ×

Work coordinate value Zero f f

Action in

era

Movement × × ×

opera-

tion

Dwell × × ×

Issuance of M, S and

T codes

× × ×

Tool length com-

pensation

× Depending on parameter

LVK(No.5003#6)

f : MDI mode

Other modes depend on pa-

rameter LVK (No.5003#6).

Cutter compensation × × f : MDI mode

× : Other modes

Storing called subpro-

gram number

× × (Note 2) f : MDI mode

× : Other modes

(Note 2)
