9. CONNECTION TO FANUC I/O Link

247

The operator’s panel connection unit (A16B–2202–0730, 0731), which

connects to the control unit via the FANUC I/O Link, acts as an interface

with the machine operator’s panel.

Connectors CM51, CM52, CMB3, and CMB4, used to interface with the

operator’s panel, feature an electrical interface and pin assignment which

are fully compatible with those of the source type output operator’s panel

connection unit for the Series 15. The following two units are available

with different numbers of I/O points:

Specifications No. of input points No. of output points

A16B–2202–0730 96 64

A16B–2202–0731 64 32

JD1B

To next device

When no other device is

connected to the connec-

tion unit, leave JD1A open.

24VDC power

BURNDY 3P CONNECTOR (Brown)

Housing: SMS3PNS–5

Contact: RC16M–SCT3

Control unit

I/O unit

Power input regulations

Voltage : 24VDC"10%

Capacity : 500+7. 3 n (mA)

n: Number of input points which are simultaneously turned on

Operator’s Panel Connection Unit

A16B–2202–0730, 0731

JD1A

(JD44A)

1 +24V

2 GND

Machine

operation’s

panel

JD1A

CM51

CM52

CMB3

CMB4

CAUTION

Use 30/0.18 (0.75 mm

) or heavier wire as the power cable.

9.9

CONNECTION OF

SOURCE OUTPUT

TYPE CONNECTION

UNIT
