1. OUTLINE OF USER PROGRAM USER PROGRAM B-63423EN/02

-4-

1.2 USABLE SOFTWARE RESOURCE FOR USER PROGRAM

Since a part of P-code custom macro program and variables are used

for FANUC standard cycle motions already, usable resource of User

Programs are limited as follows.

1) P-code Program Numbers

• O0001 - O5999

• O9000 - O9049

• O9400 - O9449

NOTE

Beside the above program numbers, some program

numbers such as O6000 -, O7000 - , O8000 - ,

O9050 - O9339 , and O9500 - can be used by User

Programs, but their contents or purpose are fixed by

MANUAL GUIDE system software as described in

this document.

So, these program number cannot be used as MTB

likes.

2) Common Variables

• #100 - #149 (#199)

• #500 - #531 (#999)

3) P-code Custom Macro Variables

• #20000 - #29999

NOTE

P-code Custom Macro Variables #10000- are used

by MANUAL GUIDE system.

So, these P-code custom macro variables cannot be

used

4) Number of G-code

• G400 – G499

NOTE

Other G codes may be used, but they are reserved

for future extensions in the MANUAL GUIDE.
