7. COMMENT OF INPUT DATA ITEM USER PROGRAM B-63423EN/02

-54-

N0101 (“20 01 C010 20”) (The 1st soft-key letters of 1st item) ;

Maximum 6ch

N010n (“20 01 C010 20”) (The n’th soft-key letters of 1st item) ;

Maximum 6ch

N0m01 (“20 01 C010 20”) (The 1st soft-key letters of m’th item) ;

Maximum 6ch

N0m0n (“20 01 C010 20”) (The n’th soft-key letters of m’th item) ;

Maximum 6ch

And the output data by selecting the soft-key can be modified.

NOTE

5 As for the output data by selecting each soft-key,

the sequence number of the third digit corresponds

to 5.

N0151 (Numeric data of the 1st soft-key to 1st item) ;

N015n (

Numeric data of the n’th soft-key to 1st item) ;

N0m51 (

Numeric data of the 1st soft-key to m’th item) ;

N0m5n (

Numeric data of the n’th soft-key to m’th item) ;
