6. COMMENT OF SOFT-KEYS FOR EACH MENU

USER PROGRAM B-63423EN/02

-32-

6.6 COMMENT OF SOFT-KEYS IN GRAPHIC FUNCTION MENU

1) Tool Path Drawing (wire-frame)

By pushing [CHECK] in the small-classified menu, the following

soft-keys are displayed. The machining program can be checked using

this drawing.

ANIME SBK ON

/OFF

SCL ON

/OFF

EXEC ERASE SCALE TOOL

POS.

PARAM RETURN

ANIME : Switch to the animated simulation screen.

SBK ON/OFF : Make a single block stop while continuous

simulation is being executed. Or, starts single

block simulation

SCL ON/OFF : Indicate whether to use scaling or not before

drawing.

EXEC : Start the continuous simulation drawing.

ERASE : Erase all drawn tool paths.

SCALE : Enlarge or reduces a part of the drawn tool

path.

TOOL POS. : Display the current tool center position with a

mark.

PARAM : Change the drawing parameters.

O700n ;

N0025 (“20 01 C010 20”) (Alphanumeric letters for ANIME) ;

Maximum 6 ch.

N0026 (“20 01 C020 20”) (Alphanumeric letters for SBK ON) ;

Maximum 6 ch.

N0027 (“20 01 C020 20”) (Alphanumeric letters for SBK OFF) ;

Maximum 6 ch.

N0028 (“20 01 C028 20”) (Alphanumeric letters for SCL OFF) ;

Maximum 6 ch.

N0029 (“20 01 C028 20”) (Alphanumeric letters for SCL ON) ;

Maximum 6 ch.

N0030 (“20 01 C030 20”) (Alphanumeric letters for EXEC) ;

Maximum 6 ch.

N0031 (“20 01 C038 20”) (Alphanumeric letters for ERASE) ;

Maximum 6 ch.

N0032 (“20 01 C040 20”) (Alphanumeric letters for SCALE) ;

Maximum 6 ch.

N0033 (“20 01 C048 20”) (Alphanumeric letters for TOOL POS.) ;

Maximum 6 ch.

N0034 (“20 01 C050 20”) (Alphanumeric letters for PARAM) ;

Maximum 6 ch.

2) Animated Simulation

By pushing [ANIME], the following soft-keys are displayed. The

machining program can be checked easily by viewing this simulation.
