MANUAL GUIDE (for Milling) Programming manual Page 37

Programming manual

Page of 603

/ 603

B-63423EN/02 USER PROGRAM 6

. COMMENT OF SOFT-KEYS FOR EACH MENU

-29-

6.3 COMMENT OF SOFT-KEYS IN MEM MENU

By pushing [MEM] in the large-classified menu, the operation menu

below is displayed. In this menu, a selected program can be run or

drawing can be performed based on the program. The soft-keys in the

menu are changed as shown below each time the rightmost key [+] is

pushed.

EXEC O

REWIND CHECK USER BGEDIT RETURN +

LIST WRK-CO OFFSET RETURN +

EXEC : Run a program.

O SEARCH : Search for a program.

N SEARCH : Search for a sequence number.

REWIND : Find the start of a block.

CHECK : Switch to the drawing screen.

USER : Display the user window screen.

BGEDIT : Switch to the BG editing screen.

O700n ;

N0125 (“20 01 C010 20”) (Alphanumeric letters for EXEC) ;

Maximum 6 ch.

N0182 (Alphanumeric letters for O SEARCH) ;

Maximum 6 ch.

N0186 (Alphanumeric letters for N SEARCH) ;

Maximum 6 ch.

N0124 (“20 01 C030 20”) (Alphanumeric letters for REWIND) ;

Maximum 6 ch.

N0177 (“20 01 C038 20”) (Alphanumeric letters for CHECK) ;

Maximum 6 ch.

N0188 (“20 01 C048 20”) (Alphanumeric letters for USER) ;

Maximum 6 ch.

N0176 (“20 01 C050 20”) (Alphanumeric letters for BGEDIT) ;

Maximum 6 ch.
