B-63423EN/02 USER PROGRAM 7. COMMENT OF INPUT DATA ITEM

-53-

The each input data item in the window can be modified by using the

following user macro program.

NOTE

1 The user program number (O761n) of this menu is

the number, which is added 10 to the number of

“Macro program number for displaying Comment of

Facing menu” in Start-up macro program. The

program number of the following each menu is

increased by 10.

(1). SQUARE menu = O761n

(2). CIRCLE menu = O762n

2 The other cycles motions menu is specified by

similar method.

For example, if it is the hole machining, the

numbers are as follows.

(1). DRILLING menu = O732n

(2). BORING menu = O733n

(3). TAPPING menu = O734n

(4). RIGID TAPPING menu = O735n

O761n ;

N9999 (Alphanumeric letters for Title(1)) ;

Maximum 40ch

N9998 (Alphanumeric letters for Title(2)) ;

Maximum 40ch

N0001 (Alphanumeric letters for 1st item) ;

Maximum 18ch

N0002 (Alphanumeric letters for 2nd item) ;

Maximum 18ch

N000m (Alphanumeric letters for m’th item) ;

Maximum 18ch

NOTE

3 The serial number of input data item counts the first

item of Input Data Window or Detail Window as an

initial term. The item is displayed in Windows (Input

Data one or Detail one) according to Data Attribute

of the next chapter.

And the comment of the soft-key for each input data item can be

modified.

NOTE

4 The soft-key to each input data item corresponds to

the sequence number of the second digit. Moreover,

the order of the displayed soft-key corresponds to

the sequence number of the fourth digit
