MANUAL GUIDE (for Milling) Programming manual Page 54

Programming manual

Page of 603

/ 603

7. COMMENT OF INPUT DATA ITEM USER PROGRAM B-63423EN/02

-46-

The each data item in the window are specified by using the following

macros.

NOTE

1 The user program number (O702n) of this menu is

the number, which is added 10 to the number of

“Macro program number for displaying Comment of

G-code menu” in Start-up macro program. The

program number of the following each menu is

increased by 10.

(1). INITIAL SET menu = O702n

(2). TOOL SETTING menu = O703n

(3). MSF CODE menu = O704n

(4). COMP. menu = O705n

(5). POSTIN menu = O706n

O702n ;

N9999 (Alphanumeric letters for Title(1)) ;

Maximum 40ch

N9998 (Alphanumeric letters for Title(2)) ;

Maximum 40ch

N0001 (Alphanumeric letters for 1st item) ;

Maximum 18ch

N0002 (Alphanumeric letters for 2nd item) ;

Maximum 18ch

N000m (Alphanumeric letters for m’th item) ;

Maximum 18ch

NOTE

2 The serial number of input data item counts the first

item of Input Data Window or Detail Window as an

initial term. The item is displayed in Windows (Input

Data one or Detail one) according to Data Attribute

of the next chapter.

And the comment of the soft-key for each input data can be modified.

NOTE

3 The soft-key to each input data item corresponds to

the sequence number of the second digit. Moreover,

the order of the displayed soft-key corresponds to

the sequence number of the fourth digit.

N0101 (“20 01 C010 20”) (The 1st soft-key letters of 1st item) ;

Maximum 6ch

N010n (“20 01 C010 20”) (The n’th soft-key letters of 1st item) ;

Maximum 6ch

N0m01 (“20 01 C010 20”) (The 1st soft-key letters of m’th item) ;

Maximum 6ch

N0m0n (“20 01 C010 20”) (The n’th soft-key letters of m’th item) ;

Maximum 6ch
