FANUC AC Servo Software 90B3 / 90B7 Series Angle based Learning Control Specification Manual Additional Manual Page 10
Additional Manual
Title 90B3 / 90B7 Angle Based
Learning Control Specification Manual
Draw No.
A - 63639E - 119
01 ’04.02.23 K.Maeda Newly designed Sheet 010
Edit Date Design Description / 10
6. Alarm
In case that there is a problem in parameter setting, the following "PARAMETER INCORRECT" displays.
Alarm
derail No.
Parameter No.
(FS15i )
Parameter No.
(FS16i )
Cause
Measures
2402 2241
2242
Case that the quotient
which divides Angle
based Learning period
by Delayed memory
number δ
δδ
δ is above 1
word.
1) Minimum time period is
increased.
2) Detective unit of reference
position is roughed and
Angle based Learning
period is decreased. (CMR
of dummy axis is
decreased.)
3) Set a fine velocity sampling
like high gain setting
2432 2243 Case that Angel
based Learning period
is smaller than 16
times Delayed
memory number δ
δδ
δ.
Minimum time period is
decreased.
2462 2246
2247
Case that Maximum
order of Gx is smaller
than Mimimum order
of Gx.
Maximum order of Gx is
increased above Minimum
order of Gx.
(Note) In case that Learning starts during clearing Learning memory, "PARAMETER INCORRECT" alarm
happens and the following inner flag is set ON without displaying alarm detail number. And this inner
flag is never cleared without power OFF.
LRNFLG#2 1 : not memory clear 0 : memory clear finish
(When N2115 = 0, N2151 = 5002, you can check at DGN N353.)
