  2. FANUC AC Servo Software 90B3 / 90B7 Series Angle based Learning Control Specification Manual

FANUC AC Servo Software 90B3 / 90B7 Series Angle based Learning Control Specification Manual Additional Manual Page 8

Additional Manual
Title 90B3 / 90B7 Angle Based
Learning Control Specification Manual
Draw No.
A - 63639E - 119
01 ’04.02.23 K.Maeda Newly designed Sheet 08
Edit Date Design Description / 10
2250
(FS16i )
Delay compensation
2663
(FS15i )
(Setting range) from –32767 to +32767 (Plus is forward, Minus is delay)
(Setting unit) nsec
When reference to M-axis (M-axis : N2227#5 = 1), one sampling is delayed. Angle based Learning
controller compensates sampling delay of reference position by this parameter. In case of sampling
0.5msec, you should set "+500" because of reference position forward.
If you refer to spindle motor command in case of using Adaptive preview control, you should set
sampling delay added the delay of Adaptive preview control. As adaptive preview control delays
command for 4msec, you should set "–3500". (–3500 = 4ms delay + 0.5msec sampling delay
compensation)
2234
(FS16i )
Learning start time
2647
(FS15i )
(Setting range) from 0 to 32767 (0 is starting at once.)
(Setting unit) msec
