FANUC AC Servo Software 90B3 / 90B7 Series Angle based Learning Control Specification Manual Additional Manual Page 7
Additional Manual
Title 90B3 / 90B7 Angle Based
Learning Control Specification Manual
Draw No.
A - 63639E - 119
01 ’04.02.23 K.Maeda Newly designed Sheet 07
Edit Date Design Description / 10
We suggest that you select minimum time period as the quotient of (Angle based Learning period)
divided by (delayed memory number) is integer.
2244
(FS16i )
Learning frequency band
2657
(FS15i )
(Setting range) Case of sampling 1msec, from 0 to 350
Case of sampling 0.5msec, from 0 to 700
(Setting unit) Hz
(Standard) Case of sampling 1msec, 100
Case of sampling 0.5msec, 150
Dlelayed memory number δ
δδ
δ and Learning frequency band fs decide Learning frequency band in angle
area fn. This fn means that Angle based Learning controller haves frequency band of fn times higher
harmonics for Learning period. This frequency band does not depend on speed, but changes in
proportion to speed from point of view of usual time area. And 0 Hz means that Learning control does
not work.
fn = fs ×δ
δδ
δ×t = fs × L (t is sampling, δ
δδ
δ is delayed memory number, L is mimimum time period)
2245
(FS16i )
Learning suspension time
2658
(FS15i )
(Setting range) from 0 to 32767 (0 is not suspension.)
(Setting unit) msec
You should set not suspension cyclces of times in usual Time based Learning control but suspension
time in Angle based Learning control. This specification is compatible with Spindle Learning control.
This parameter does not relate with No.2008#4 (suspension / continuation) in Angle based.
2246
(FS16i )
Maximum order of Gx
2659
(FS15i )
(Note) Gx : Dynamic characteristic compensation
2247
(FS16i )
Mimimum order of Gx
2660
(FS15i )
(Setting range) from 0 to 32767 (Minimun order < Maximum order)
This setting is compatible with usual Time based Learning control. If Maximum order is 0, servo
software sets 12 internally.
2248
(FS16i )
Maximum coefficient of Gx
2661
(FS15i )
2249
(FS16i )
Mimimum coefficient of Gx
2662
(FS15i )
(Setting range) from –32767 to +32767
This setting is compatible with usual Time based Learning control. If Maximum coeficient is 0, servo
software sets 64 internally. And if Mimimum coeficient is 0, servo software sets (32 – Maximum
coeficient) internally.
