FANUC AC Servo Software 90B3 / 90B7 Series Angle based Learning Control Specification Manual Additional Manual Page 9

Additional Manual
Title 90B3 / 90B7 Angle Based
Learning Control Specification Manual
Draw No.
A - 63639E - 119
01 ’04.02.23 K.Maeda Newly designed Sheet 09
Edit Date Design Description / 10
5. PMC signal
If you input the following PMC signal, Angle based Learning control starts and finishes at point of any time
without G05.
This function can be used in Series 16i –B with supported General purpose DI/DO.
#7 #6 #5 #4 #3 #2 #1 #0
G0320
SVDI08 SVDI07 SVDI06 SVDI05 SVDI04 SVDI03 SVDI02 SVDI01
SVDI0x Angle based Learning control (x is axis number.)
0: finishes.
1: starts.
#7 #6 #5 #4 #3 #2 #1 #0
G0322
SVDI28 SVDI27 SVDI26 SVDI25 SVDI24 SVDI23 SVDI22 SVDI21
SVDI2x Velocity integrator is
0: available. (usually)
1: not available.
(Note) SVDI2x signal is used for purpos of removing abnormal torque when cog fitting is finished
in gear cutting.
#7 #6 #5 #4 #3 #2 #1 #0
F0320
SVDO08 SVDO07 SVDO06 SVDO05 SVDO04 SVDO03 SVDO02 SVDO01
SVDO0x Learnig control flag (for observing)
0: normal
1: Learnig control is executing.
#7 #6 #5 #4 #3 #2 #1 #0
F0322
SVDO28 SVDO27 SVDO26 SVDO25 SVDO24 SVDO23 SVDO22 SVDO21
SVDO2x Learnig memory clear flag (for observing)
0: normal
1: during clearing Learning memory.
