Series 16i/160i-LA Parameter manual Page 15

Parameter manual
B–63200EN/03
4. DESCRIPTION OF PARAMETERS
9
#7
15002
#6
PSH
#5 #4 #3 #2 #1
ADC
#0
BMA
[Data type] Bit
BMA When the shutter is closed in automatic operation, beam output is:
0 : Disabled. (Normal operation)
1 : Enabled. (Maintenance)
ADC AD conversion–2 data is judged with:
0 : The select signal.
1 : The DI signal. (Normal operation)
PSH Of the discharge tubes,
0 : All are used.
1 : Half are used.
#7
15003
#6 #5 #4 #3 #2
GVW
#1
HPT
#0
TIV
[Data type] Bit
TIV The sign (+/–) of the tracing displacement amount is:
0 : Not inverted.
1 : Inverted.
HPT When piercing is lengthened or reduced, a parameter setting is:
0 : Rewritten.
1 : Not rewritten.
GVW RUN–OFF evacuation is:
0 : Disabled. (Maintenance)
1 : Enabled. (Normal operation)
#7
CWY15004
#6
ECH
#5 #4
EDG
#3 #2
SPB
#1
STC
#0
AGC
[Data type] Bit
AGC The ”G32 P_;” command (with Q, T, and R not specified) is used as:
0 : A flow pattern command.
1 : A direct gas pressure control command.
STC The shutter is controlled by:
0 : A G code.
1 : An external signal.
SPB During a skip, beam output is:
0 : Performed.
1 : Not performed.
EDG When the assist gas is switched in edge machining, the beam is:
0 : Turned off.
1 : Not turned off.
ECH Upon reset, the active E number is:
0 : Not cleared.
1 : Cleared.
CWY The oscillator of the:
0 : CO
2
laser is used.
1 : CW–YAG laser is used.
