Series 16i/160i-LA Parameter manual Page 76

Parameter manual
4. DESCRIPTION OF PARAMETERS
B–63200EN/03
70
15703 Mirror block axis selection
[Data type] Byte
[Unit of data]
[Valid data range] 4 to 8
Specify the axis number of an axis of mirror movement. The axis must not
be the X–axis, Y–axis or Z–axis.
15704 Mirror block axis reference position calibration
[Data type] Word
[Unit of data]
Increment system Unit IS–A IS–B IS–C
Metric input mm 10.0 1.0 0.1
Inch input inch 1.0 0.1 0.01
[Valid data range] –32768 to 32767
[Standard setting] 0
Specify a distance from the origin for the position calibration of the mirror
block axis so that an optimum transmission distance can be obtained.
15705 Optical path length calibration coefficient
[Data type] Word
[Unit of data] 1/64
[Valid data range] 64 to 32767
[Standard setting] 128
The total amount of travel along the axis specified in parameter No. 15700
divided by this coefficient is the amount of travel along the mirror block
axis.
