4. DESCRIPTION OF PARAMETERS
71
15710 Cylinder level check wait time
[Data type] Word
[Unit of data] Second
[Valid data range] 0 to 32767
Specify a wait time for checking the cylinder level.
15711 Gas mixture wait time
[Data type] Word
[Unit of data] Minute
[Valid data range] 0 to 32767
[Standard setting] 60
Specify the time from when the tank is filled with gases until the gases are
mixed and ready to be supplied.
15712 Mixer evacuation time
[Data type] Word
[Unit of data] Minute
[Valid data range] 0 to 32767
[Standard setting] 30
Specify the evacuation time for evacuating the mixer. This value is also
used as the evacuation time used for a leak check.
15713 Helium discharge time
[Data type] Word
[Unit of data] Millisecond
[Valid data range] 0 to 32767
Specify the time allowed to discharge helium gas from the piping after the
piping is filled with helium gas and before being filled with another gas.
15714 Nitrogen and CO2 discharge time
[Data type] Word
[Unit of data] Millisecond
[Valid data range] 0 to 32767
Specify the time allowed to discharge nitrogen or CO
2
from the piping
after the piping is filled with nitrogen or CO
2
and before being filled with
another gas.
4.30
LASER GAS
MIXTURE FUNCTION
