5. Connection object (05H)
Attribute
Unsupported
Service Unsupported
Object class
Maximum available number of
active connections
1
Section Information Maximum number of
instances
Instance type Explicit Message 1
Production
trigger
Cyclic
Transport type Server
Transport class 3
ID Description
GET SET Value
1 State O X
2 Instance type O X 00H
3 Transport class trigger O X 83H
4 Produced connection ID O X
5
Consumed connection ID
O X
6
Initial comm. Characteristics
O X 21H
7
Produced connection size
O X FE00H
8
Consumed connection size
O X FE00H
9 Expected packed rate O O
12
Watchdog time-out action
O O One of 01,03
13 Produced connection path length O X 0000
14
Produced connection path
O X
15 Consumed connection path length O X 0000
16
Consumed connection path
O X
Attribute
17 Production inhibit time O X
DeviceNet service Parameter option
05H Reset No
0EH Get_attribute_Signle No
Object
instance 1
Service
10H Set_attribute_Signle No
