DeviceNet Board Operators manual Page 56

Operators manual
1.DeviceNet FUNCTIONS OPERATION B-63404EN/03
- 44 -
Diagnostics
900 Communications status of slave No.1
Indicates the communications status of slave No.1.
This diagnostic is equivalent to the "STATUS" setting in screens
1.2.2 (a), 1.2.2 (b) and 1.2.2(c).
Value
Display on Screens
1.2.2 (a), 1.2.2 (b) and 1.2.2(c)
Meaning
0 DISABLE Disables communications.
1 ENABLE Enables communications.
2 Reserved
3 ERROR Communications error has occurred.
For details, check CONDITION, status of STATUS information (R area)
and the error status of the slave device.
129 Reserved
130 INVALID MAC ID The MAC-ID is not set correctly.
131 Reserved
132 DUPLICATE MAC ID Duplicate MAC-IDs have been set.
133 DUPLICATE DEVICE A MAC-ID duplicating the bus parameter has been set.
134
135
136
137
138
139
140
141
142
Reserved
143 INVALID CONNECTION Connection by the correct I/O Connection is not made.
The connection by these DeviceNet master functions is Poll I/O
Connection.
144
145
146
Reserved
POWER ON ERROR An error occurred when the power was turned ON or when ENABLE was
set.
Check the network cable connections or DeviceNet interface board
mounting state.
