DeviceNet Board Operators manual Page 62

Operators manual
1.DeviceNet FUNCTIONS OPERATION B-63404EN/03
- 50 -
Table 1.3 (a): Setting items in slave function screen
Item Description
1.DIS/ENB
(DISABLE/ENABLE)
Sets whether to disable or enable
communications.
Move the left and right cursor keys to select this
parameter setting. (For the 15i-A, use soft keys.)
Set ENABLE after setting of the master function
parameters is completed.
Communications is started a few seconds after
setting ENABLE.
DISABLE : Disables communications.
ENABLE : Enables communications.
2.MAC-ID Sets the number for identifying on the network the
DeviceNet interface board mounted on the control
unit (CNC).
Set a number that does not duplicate the MAC-ID
of other nodes on the network within the range 0 to
63.
(MAC-ID: Media Access Control ID)
3.BAUD-RATE Sets the baud rate.
The setting range is 0 to 2.
The baud rate for each setting is as follows:
0: 125 kbps
1: 250 kbps
2: 500 kbps
The baud rate is limited by the maximum network
length and other factors. For details, refer to
"Connecting DeviceNet Functions" in the
Connections section.
4 DI ADDRESS
5 DI SIZE
6 DO ADDRESS
7 DO SIZE
Set the areas to be used as the DI/DO data
buffers.
Set the leading buffer address and buffer size.
Use the R area as the address to be set.
Size setting range: 0 to 64
8.STATUS ADDRESS
9.STATUS SIZE
Set the areas to be used as the status information
data buffer.
Set the leading buffer address and buffer size.
Use the R area as the address to be set.
Size setting range: 0 to 4
10. DI HOLD/CLEAR
Note) See Chapter 2,
"Configuring a
Safe System."
Specify whether to hold or clear DI data if
communication is abnormal.
0: To hold DI data.
1: To clear DI data.
