DeviceNet Board Operators manual Page 58

Operators manual
1.DeviceNet FUNCTIONS OPERATION B-63404EN/03
- 46 -
1.3 SETTING SLAVE FUNCTIONS
To use the DeviceNet slave functions, you must set the MAC-ID,
baud rate and address assignments.
The "MAC-ID (Media Access Control ID)" is the ID used for
identifying on the network the DeviceNet communications board that
is currently mounted on the CNC.
This MAC-ID is set to a value within the range 0 to 63, and must not
duplicate the ID of another node on the network. The "baud rate" is
the network's communicating speed. Set the same value as the baud
rate currently set for communications on the network. (Refer to the
baud rate setting of the master device currently used on the network.)
"Address assignment" refers to setting of the DI/DO sizes when I/O of
the DI/DO signals is performed and to setting of the PMC addresses
(addresses of R areas) that are used.
Setting Slave Functions on Series 16i/18i/21i-A/B
Procedure (CRT/MDI)
(1) Press function key
SYSTEM
and then soft key [PMC] to switch to
the PMC screen.
(2) If you press soft keys [PMCDGN] → ([>])→ [I/OCHK] →
[D_NET] in that order, the DeviceNet Function initial screen
(screen 1.2 (a) below) is displayed.
If you press [SLAVE] in this screen, the slave function setup
screen (screen 1.3(a) or 1.3(c)) is displayed.
You can enter setting values in this screen provided that the following
conditions are satisfied:
(a) Setting parameter PWE must be set to "1".
(b) The unit must be in the MDI mode or in an emergency stop
state.
(c) "DISABLE" must be selected at the "1 DIS/ENB" item.
Table 1.3(a) shows the setting items in this screen.
STATUS and COMMUNUNICATION STATUS are displayed in this
screen as diagnostics information used for verifying the
communications status.
Table 1.3(b) describes this diagnostics information.
