Embedded macro for measurement Supplement to Manual Page 11

Supplement to Manual
2000/02/08 H. Minami
A-78392EN
FANUC Series 16i/18i/21i-MA
Embedded macro for measurement
Title
Drawing No.
Page
Descri
p
tionDateEdit
11/36
G54.1P1
↔
P48 : (
1001
: G54 P1,
1002
: G54 P2……….
1048
: G54 P48)
Movements
:
X and Y single surface
1. The probe moves within the distance (D +
γ
) with the feed-rate (f) until touching the
measuring surface.
→
First measurement
2. Return the distance (
β
) with a rapid traverse.
3. Moving within the distance (
β
+
γ
) with the feed-rate (F) until touching the measuring
surface.
→
Second measurement
Z single surface
1. The probe moves within the distance (D +
γ
- stylus radius) with the feed-rate (f) until
touching the measuring surface.
→
First measurement
2. Return the position (1
st
measuring point +
β
) with a rapid traverse.
3. Moving within the distance (
β
+
γ
) with the feed-rate (F).
→
Second measurement
When
G180
is executed, the system will output a measurement position to the work-piece
origin offset value and the following variables.
β
1
st
Measure
Measuring
surface
γ
2
nd
Measure
D
Measuring
start point
1
st
Measure
2
nd
Measure
Measuring
start point
γ
D
β
Measuring
surface
