  2. Embedded macro for measurement

Embedded macro for measurement Supplement to Manual Page 4

Supplement to Manual
2000/02/08 H. Minami
A-78392EN
FANUC Series 16i/18i/21i-MA
Embedded macro for measurement
Title
Drawing No.
Page
Descri
p
tionDateEdit
4/36
2-2. Macro variable for measuring cycles
The following variables are necessary to control the movement of a probe. Please be sure
to set these variables before using measuring cycles.
Note) If the following data is empty or zero, the alarm is occurred.
#210
: Feed-rate for the first measurement (f)
#211
: Approach distance for the first measurement (
α
)
#212
: Escaping distance for the first measurement (
β
)
= Approach distance for the second measurement
#213
: Overlap distance for measurement (
γ
)
The offset amounts between stylus ball center and spindle center
#214
: Feed-rate for approaching start point (fa)
If the probe collide with work-piece (fa), the alarm will occur and stop
immediately.
#215
: Escaping distance for the second measurement (
ε
)
α
αα
α
Measuring
start
p
oint
fa
γ
γγ
γ
f
Measuring
surface
β
ββ
β
ε
εε
ε
F
β
ββ
β
γ
γγ
γ
Measuring
start
p
oint
1
st
Measurement 2
nd
Measurement
