Embedded macro for measurement Supplement to Manual Page 24

Supplement to Manual
2000/02/08 H. Minami
A-78392EN
FANUC Series 16i/18i/21i-MA
Embedded macro for measurement
Title
Drawing No.
Page
Descri
p
tionDateEdit
24/36
4-9. Inside corner measurement (G188)
This is a menu for measuring an inside corner position.
Create ISO code program in the following form.
G188 C A B U V I J F W ;
C
: Corner position
Input the corner position (1, 2, 3, 4).
A
: 1
st
measure point X
Input the approximate X coordinate of the first measuring point.
B
: 1
st
measure point Y
Input the approximate Y coordinate of the first measuring point.
U
: Distance for X axis
Input the distance from measuring start point to single surface of X axis.
V
: Distance for Y axis
Input the distance from measuring start point to single surface of Y axis.
I
: Increment for X axis
Input the increment from the first point to the second point for X axis.
J
: Increment for Y axis
Input the increment from the third point to the fourth point for Y axis.
F
: Feed rate for movement
Input the feed-rate for movement on measuring.
W
: Work coordinate system number
Input the work-piece coordinate system number which will be set.
G54
↔
G59 : (
1
: G54,
2
: G55,
3
: G56,
4
: G57,
5
: G58,
6
: G59)
G54.1P1
↔
P48 : (
1001
: G54 P1,
1002
: G54 P2……….
1048
: G54 P48)
1
2
3
4
(
A
,
B
)
J
U
V
Measuring
start
p
oint
[
1
]
[
2
]
[
3
]
[
4
]
Corner
p
osition
C
