B-63834EN/02 MANUAL GUIDE 0i 1.MANUAL GUIDE 0i

- 645 -

When the user first enters the help topic, text-based information is

displayed. When the user presses the “GRAPH.” soft-key, any

graphical information for that topic is displayed. In this way, the user

can confirm that the selected topic pertains to the information that

they need.

NOTE

For some G-codes, there are no graphical help

screens. In these cases, no graphical help screen is

displayed when you press “GRAPH”.

The user can either return to the editor by pressing the Left Arrow

soft-key on the display unit, or directly enter the required information

into the help screen. To insert the program information into the help

screen, the user simply has to type in the command and press the

“INSERT” key on the MDI key panel. For our example, let’s set the

X- and Z-axes to 1.0. Since we have confirmed that the G01 command

is, in fact, the command we want, we would type in

“G01X1.Z1.[EOB]” (where “EOB” is the End of Block key on the

G01 LINEAR MOVE

G01 WILL MOVE THE AXES AT PROGRAMMED

FEEDRATE TO THE END POINT SPECIFIED BY

THE PROGRAMMED COORDINATES.

[TEXT ][GRAPH. ][ ][ ][ ]

G01 LINEAR MOVE

G01 EXAMPLE

START AT X0.0 Z0.0

LINEAR MOVE TO X100. Z100.0 FEED AT F0.5

G01 X100. Z100.0 F0.5

[TEXT ][GRAPH. ][ ][ ][ ]

START
