PROGRAMMING5. FEED FUNCTIONS

B–63834EN/02

NOTE

An upper limit is set in mm/min or inch/min. CNC calculation

may involve a feedrate error of ±2% with respect to a

specified value. However, this is not true for

acceleration/deceleration. To be more specific, this error is

calculated with respect to a measurement on the time the

tool takes to move 500 mm or more during the steady state:

See Appendix C for a range of feedrates that can be specified.

Dwell G04 X_ ; or G04 U_ ; or G04 P_ ;

X_ : Specify a time (decimal point permitted)

U_ : Specify a time (decimal point permitted)

P_ : Specify a time (decimal point not permitted)

By specifying a dwell, the execution of the next block is delayed by the

specified time.

Bit 1 (DWL) of parameter No. 3405 can specify dwell for each rotation

in feed per rotation mode (G99).

Table 5.4 (a)

Command value range of the dwell time (Command by X or U)

Increment system Command value range Dwell time unit

IS–B 0.001 to 99999.999

IS–C 0.0001 to 9999.9999

s or rev

Table 5.4 (b)

Command value range of the dwell time (Command by P)

Increment system Command value range Dwell time unit

IS–B 1 to 99999999 0.001 s or rev

IS–C 1 to 99999999 0.0001 s or rev

D Reference

5.4

DWELL (G04)

Format

Explanations
