Series 0i - TB Operators manual Page 799

Operators manual
APPENDIX
B–63834EN/02
G. ALARM LIST
773
No. DescriptionFaulty location and remedy
SPM
indica-
tion(*1)
Message
9055 SPN_n_ : POWER LINE
SWITCH ER-
ROR
55 1 Replace the magnetic contactor.
2 Check and correct the sequence.
The power line state signal of the
magnetic contactor for selecting a
spindle or output is abnormal.
9056 SPN_n_ : INNER COOL-
ING FAN STOP
56 Replace the SPM unit. The cooling fan in the SPM control
circuit stopped.
9057 SPN_n_ : EX DECEL-
ERATION
POWER
57 1 Decrease the acceleration/decel-
eration duty.
2 Check the cooling condition (pe-
ripheral temperature).
3 If the cooling fan stops, replace the
resistor.
4 If the resistance is abnormal, re-
place the resistor.
An overload was detected in the re-
generative resistance. (PSMR alarm
indication: 8)
Thermostat operation or short–time
overload was detected.
The regenerative resistor was dis-
connected, or an abnormal resis-
tance was detected.
9058 SPN_n_ : OVERLOAD IN
PSM
58 1 Check the PSM cooling status.
2 Replace the PSM unit.
The temperature of the radiator of the
PSM has increased abnormally.
(PSM alarm indication: 3)
9059 SPN_n_ : COOLING FAN
STOP IN PSM
59 Replace the SPM unit. The cooling fan in the PSM stopped.
(PSM alarm indication: 2)
9062 SPN_n_ : MOTOR VCMD
OVER-
FLOWED
62 Check and correct the parameters.
(No. 4021, 4056~4059)
The specified motor speed is too
large.
9066 SPN_n_ : AMP MODULE
COMMUNICA-
TION
66 1 Replace the cable.
2 Check and correct the connection.
An error was found in communication
between amplifiers.
9073 SPN_n_ : MOTOR SEN-
SOR DISCON-
NECTED
73 1 Replace the feedback cable.
2 Check the shield processing.
3 Check and correct the connection.
4 Adjust the sensor.
The motor sensor feedback signal is
not present.
9074 SPN_n_ : CPU TEST ER-
ROR
74 Replace the SPM control printed–cir-
cuit board.
An error was detected in a CPU test.
9075 SPN_n_ : CRC ERROR 75 Replace the SPM control printed–cir-
cuit board.
An error was detected in a CRC test.
9079 SPN_n_ : INITIAL TEST
ERROR
79 Replace the SPM control printed–cir-
cuit board.
An error was detected in an initial test
operation.
9081 SPN_n_ : 1–ROT MO-
TOR SENSOR
ERROR
81 1 Check and correct the parameter.
2 Replace the feedback cable.
3 Adjust the sensor.
The one–rotation signal of the motor
sensor cannot be correctly detected.
9082 SPN_n_ : NO 1–ROT
MOTOR SEN-
SOR
82 1 Replace the feedback cable.
2 Adjust the sensor.
The one–rotation signal of the motor
sensor is not generated.
9083 SPN_n_ : MOTOR SEN-
SOR SIGNAL
ERROR
83 1 Replace the feedback cable.
2 Adjust the sensor.
An irregularity was detected in a mo-
tor sensor feedback signal.
