1.MANUAL GUIDE 0i MANUAL GUIDE 0i B-63834EN/02

- 682 -

1.5.4 1.5.4 Details of Auxiliary Calculation

This chapter explains the details of the auxiliary calculation.

By using this auxiliary calculation, the coordinates of a point or the

angle of a line can be determined. Furthermore, the form of a contour,

such as the amount of shift from the original form for a tool radius

can be entered easily.

1.5.4.1 General

(1) Data items in which auxiliary calculation can be used

(a) Start point

- Coordinate (X, Z) of start point

(b) Line

- Coordinate (X, Z) of end point

- Angle of a line (A)

- Coordinate (X, Z) of end point

- Coordinate (I, K) of center

- Specifying an arc

(2) Calculation type available in auxiliary calculation

(a) Calculation of coordinate

- A point specified by polar coordinate

- A point specified by a point, angle and distance

- A point specified by rotating a point

- Neighbor point of a line

- Cross point between 2 lines

- Cross point between line and arc

- Cross point between 2 arcs

(b) Calculation of angle

- Angle of the line passes 2 points

- Angle of a line rectangular to the line passes 2 points

- An arc passes 1 point and its center coordinate has

been determined

- An arc passes 2 points and its radius has been

determined

- An arc passes 3 points
