Series 0i - TB Operators manual Page 720

Operators manual

Page of 829

/ 829

1.MANUAL GUIDE 0i MANUAL GUIDE 0i B-63834EN/02

- 694 -

1.6 PARAMETER

9050

STGECF

STFECF Cutting feedrate override at the start of cutting in drilling.

Valid data range : 0 to 255 Units : 1%

9292

S1TTMN

S1TTMN M-code output before normal tapping in turning

Valid data range : 0 to 999 Units : 1%

When 0 is set to this parameter, this M-code is not output

9293

S1TTMR

S1TTMR M-code output before reverse tapping in turning

Valid data range : 0 to 999 Units : 1%

When 0 is set to this parameter, this M-code is not output

9294

S1STPM

S1STPM M-code for stopping

Valid data range : 0 to 999 Units : 1%

When 0 is set to this parameter, M05 is output

9295

S1NMLM

S1STPM M-code for rotating spindle CW direction

Valid data range : 0 to 999 Units : 1%

When 0 is set to this parameter, M03 is output

9296

S1RVSM

S1STPM M-code for rotating spindle CCW direction

Valid data range : 0 to 999 Units : 1%

When 0 is set to this parameter, M04 is output

9330

TMPPNO

TMPPNO The program number that will be used as a temporary program storing

area for NC program conversion. When 0 is set, warning message will

be displayed and NC program conversion will never start.

Contents Summary of Series 0i - TB Operators manual

Page 1OPERATOR’S MANUAL B-63834EN/02
