POWER MATE 0 Maintenance manual Page 131

Maintenance manual
4. INTERFACE BETWEEN NC AND PMC
B–63445EN/01
116
Symbol PMC addressSignal name
OUT0 to OUT7 Software operator’s panel general purpose switch signal F072
OVC Override cancel signal G006#4
PN0 to PN3 Workpiece number search signal G009
ROV1, ROV2 Rapid traverse override signal G014#0, #1
ROV1O, ROV2O Rapid traverse override signal (software operator’s panel) F076#4, #5
RRW Reset & rewind signal G008#6
RST CNC reset signal F001#1
RT Manual rapid traverse select signal G019#7
RTO Manual rapid traverse signal (software operator’s panel) F077#6
RWD Rewinding signal F000#0
S00 to S31 Spindle function code signal F022 to F025
SA Servo ready signal F000#6
SAR Spindle speed arrival signal G029#4
SBK Single block signal G046#1
SBKO Single block signal (software operator’s panel) F075#3
SF Spindle function strobe signal F007#2
SFIN S function end signal G005#2
SKIP Skip signal X000#7
SOR Spindle orientation signal G029#5
SOV0 to SOV7 Spindle speed override signal G030
:
SP Feed hold signal G008#5
:
SPO Feed hold signal (software operator’s panel) F075#7
SPL Feed hold lamp signal F000#4
:
SSTP Spindle stop signal G029#6
ST Cycle start signal G007#2
STL Cycle start lamp signal F000#5
SVF1, SVF2 Servo off signal G126#0, #1
T00 to T31 Tool function code signal F026 to F029
TF Tool function strobe signal F007#3
TFIN T function end signal G005#3
UI0 to UI15
Custom macro input signal G054, G055
UO0 to UO15
UO100 to UO131
Custom macro output signal F054, F055, F056
to F059
ZP1, ZP2 Reference position return end signal F094#0, #1
ZRF1, ZRF2 Reference position establishment signal F120#0, #1
