POWER MATE 0 Maintenance manual Page 206

Maintenance manual
APPENDIX
B–63445EN/01
B. LIST OF MAINTENANCE
PARTS
193
Consumables here refer to the parts which are not reused after
replacement. Rank : A>B>C
Name Drawing number Vender Remarks Rank
Fan motor A90L-0001-0385 SANYO A
Battery A98L-0031-0006 SANYO A
Fuse A60L-0001-0046#5.0R DAITO 5. 0A Contorol unit B
A60L-0001-0175#3.2R 3. 2A CRT/ MDI, I/O card B
key board A86L-0001-0171#SM2R FUJITSU A02B-0166-C201#TR B
A86L-0001-0171#SM2S A02B-0120-C201#TS B
Plastic case A230-0476-T006 FANUC A02B-0166-B591 C
Maintenance Parts (Parts to be repaired by us)
Name Drawing number Vender Remarks Rank
Power supply PCB A20B-1004-0960 FANUC B
Base PCB A16B-2100-0160 FANUC TYPE B B
Built-in I/O card C A20B-2001-0902 FANUC DI:32, DO:24(Source type) B
Analog spindle module A20B-2902-0235 FANUC Analog spindle B
PMC control module A A20B-2900-0142 FANUC PMC-PA1 B
CRT control module A20B-2901-0480 FANUC B
CRT control P.C.B A20B-2000-0840 FANUC B
DPL control PCB A20B-2100-0680 FANUC B
CRT/MDI A02B-0166-C201#TR FANUC For CE marking B
A02B-0166-C201#TS FANUC For CE marking B
DPL/MDI A02B-0166-C301#R FANUC B
CRT display device A61L-0001-0093 MATSUSHITA Usable unit
A02B-0166-C201#TR
A02B-0166-C201#TS
B
B.1
MAINTENANCE
PARTS
Maintenance Parts
(Consumable)
