POWER MATE 0 Maintenance manual Page 73

Maintenance manual
2. HARDWARE
B–63445EN/01
58
NAME Specification Servo
interface
Remarks
Power Mate 0 Basic unit A02B–0166–B591 TYPE B
NAME Specification Remarks
Base PCB A16B–2100–0160 TYPE B
Power supply PCB A20B–1004–0960
NAME Specification Remarks
PMC controled module A A20B–2900–0142 PMC–PA 1
CRT controled module A20B–2901–0480
Analog spindle module A20B–2902–0235 Analog spindle
Name Specifications Remarks
CRT/MDI A02B–0166–C201#TR English key
A02B–0166–C201#TS Symbol key
DPL/MDI A02B–0166–C301#R
Name Specifications Remarks
CRT control PCB A20B–2000–0840
DPL control PCB A02B–2100–0680
2.5
LIST OF PRINTED
BOARD AND UNIT
2.5.1
Basic Unit
2.5.2
Control Unit Printed
Board
2.5.3
Module
2.5.4
CRT/MDI, DPL/MDI Unit
2.5.5
Setting and Display
Unit
