POWER MATE 0 Maintenance manual Page 245

Maintenance manual
FANUC Power Mate 0
Maintenance manual
TITLE
THE SPECIFICATION OF LED
The LED used by Power Mate 0 is four like the below figure, and you can
check whether the result of the rotary switch operation is normal or alarm
according to the display. It is necessary to turn off and on the power supply
again when any alarm occurs.
Disposition of LED Signal
S1 S0
WD EN
● ●
○ ○
Red Green
Each action of rotary switch and display of LED
Selecting value Action State in action State of normal end State of alarm
０ Normal condition
５ Clearing of non-volatile
RAM.
８ Backup the contents of
the non-volatile RAM to
a flash memory card.
Ａ Restore the contents of a
flash memory card to the
RAM.
Note1)
● ？
○ ●
Note1)
○ ？
○ ●
● ○
○ ●
○ ●
○ ●
○ ●
○ ●
● ○
○ ●
△ △
○ ●
Note2)
○ ●
○ ●
● ○
○ ●
△ △
○ ●
Note3)
Note 1) The LED of S0 is on when the machine coordinate is 0, and it is off when the
machine coordinate is not 0.
Note 2) S0 and S1 turn on and off alternately
Note 3) S0 and S1 turn on and off simultaneously (You may not be able to confirm blinking
simultaneously, for action time is too short.)
example
○ ： Turn off
△ ： Turn on or off
● ： Turn on
？ ： Indefinite
B-63445EN/01-2
3 / 4
EDIT
DATE DESIG. DESCRIPTION
DRAW.NO.
CUST.
SHEET
01
020118
New design
