3.2.Data displayed in Monitor Screen
Displayed data in Monitor screen is showed below.
Display range is the range which can be displayed on screen and not capacity of system.
1) Data of servo motor
Data (Unit) Data type Display range Required parameter
Accumulated command pulse (pulse) 1 Word ±99999999
Accumulated feedback pulse (pulse) 2 Word ±99999999
Position error (pulse) 2 Word ±99999999
Reference counter (pulse) 2 Word ±99999999
Actual speed (min
-1
) 1 Word -32768 - +32767
Command current (%) 1 Word ±300
Thermal simulation data (%) 1 Word 0 - 300
Torque (%) 1 Word ±300
Disturbance torque (%) Note 1) 1 Word ±14564 No.2104(Cut), No2142(Rapid)
Optional data Note 2) 1 Word -32768 - +32767
Optional data 2 Note 2) 1 Word -32768 - +32767
R-phase current (%) 1 Word ±300
Effective current (%) 1 Word ±300
Pulse coder AMR data 1 Word 0 - 255
Internal neglect counter 1 Word 0 - +32767
External neglect counter 1 Word 0 - +32767
Internal correction counter 1 Word 0 - +32767
External correction counter 1 Word 0 - +32767
V-ready off information 1 Word -32768 - +32767
Note 1) Disturbance torque (%)
Set the following parameters to display the ratio of load torque to unexpected disturbance detection threshold.
- No.2104 (unexpected disturbance detection threshold for cutting)
- No.2142 (unexpected disturbance detection threshold for rapid traverse)
If these parameters are set to 0, load torque is displayed as it is. In this case, ±7282 means the max torque of servo
moter.
Note 2) Optional data 1, Optional data 2
Optional data 1 and Optional data 2 are used for maintenance by FANUC serviceman.
