SERIES 15i-16i-18i-21i MODEL A Operators manual Page 42

Operators manual
B-63454EN/01 4. OPERATION
-33-
Send Input >
Selects the data to be sent to the CNC.
File >
Others Setting comm
Makes settings related to the serial port.
Folder setting
Makes directory settings such as file input/output.
Select Path >
Not used
AutoGetScreen >
Chooses whether to transfer screen data automatically.
MDIkey >
Not used
Keyfree(Q)
To be chosen when soft key operation is disabled during operation
CNC MDI Key(C)>
Not used
Help Version info
Displays the version of the host software.
4.1.3 Other Buttons
(a) Get Screen button
This button is used to acquire CNC screen data (character data).
(b) Soft keys
Choosing a soft key has the same effect as pressing a soft key on
the CNC.
(c) Page UP and Page DOWN keys
Choosing these keys has the same effect as pressing the MDI keys
PAGE UP and PAGE DOWN on the CNC.
These buttons are used in combination with each other.
(See also: Section 4.5)
