SERIES 15i-16i-18i-21i MODEL A Operators manual Page 43

Operators manual
4. OPERATION B-63454EN/01
−34−
4.2 FILE MENU
4.2.1 Print
The user can print the data currently displayed on the host software.
NOTE
The printer to be used needs to be set in Windows
beforehand.
4.2.2 US version/Japanese version
The user can select the language used, for example, for the host
software menus.
For the Series 16i/18i/21i
At the same time, the user must choose the type of CNC screen data
display and the number of soft keys.
US version →
80 characters wide : Display in English/80 characters wide/10
soft keys
40 characters wide : Display in English/40 characters wide/5 soft
keys
Japanese version →
80 characters wide : Display in Japanese/80 characters wide/10
soft keys
40 characters wide : Display in Japanese/40 characters wide/5
soft keys
For the Series 15i
US version : Display in English
Japanese version : Display in Japanese
4.2.3 Exit
This menu item quits this software (remote diagnosis host software).
