B-63454EN/01 APPENDIX B.
CNC PARAMETERS RELATED TO REMOTE DIAGNOSIS
-63-
[Data type] Integer
[Valid data range] 0 to 99999999
Parameter No. 0042, No. 0044, and No. 0046 above are used to set
passwords for using the remote diagnosis function.
With the remote diagnosis function, the passwords described below are
used to prevent unauthorized persons from accessing system
parameters and machining programs without permission.
Password 1:
Set a password for all remote diagnosis services. (If this password
is not entered on the host (personal computer, for example), none
of the remote diagnosis function services are available.)
Password 2:
Set a password for part programs. (If this password is not entered
on the host (personal computer, for example), operations such as
program input/output and checking cannot be performed.)
Password 3:
Set a password for parameters. (If this password is not entered on
the host (personal computer, for example), operations such as
parameter input/output cannot be performed.)
Parameter No. 0043, No. 0045, and No. 0047 above are used to set the
keywords corresponding to the passwords for the remote diagnosis
function.
Keyword 1: Keyword for password 1 (parameter No. 0042)
Keyword 2: Keyword for password 2 (parameter No. 0044)
Keyword 3: Keyword for password 3 (parameter No. 0046)
When a value other than 0 is set as a password (parameter No. 0042, No.
0044, or No. 0046), the password can be changed only if the same value
is set as the corresponding keyword.
NOTE
Once a value other than 0 is set as a password, the
password can be changed only if the same value as
the corresponding keyword (parameter No. 0043, No.
0045, or No. 0047) is set. If a value other than 0 is set
as a password, the setting of the password is not
displayed on the parameter screen (a blank
appears). Care is necessary when setting
passwords.
The values of the keywords are set to 0 when the
power is turned on. The parameter screen does not
display the setting of each keyword (a blank
appears).
5001 Device number of a reader/punch connected to JD5A of the main unit
[Input type] Setting input
[Data type] Integer
[Valid data range] 1 to 6
