SERIES 15i-16i-18i-21i MODEL A Operators manual Page 75

Operators manual
B.
CNC PARAMETERS RELATED TO REMOTE DIAGNOSIS
APPENDIX B-63454EN/01
-66-
5132 Baud rate of the reader/punch corresponding to device number 3
5142 Baud rate of the reader/punch corresponding to device number 4
5152 Baud rate of the reader/punch corresponding to device number 5
5162 Baud rate of the reader/punch corresponding to device number 6
[Input type] Setting input
[Data type] Integer
[Valid data range] 1 to 12
Set the baud rate of the reader/punch corresponding to each device
number. The table below indicates the relationship between the set
numbers and baud rates.
Set number Baud rate Set number Baud rate
1 50 7 600
2 100 8 1200
3 110 9 2400
4 150 10 4800
5 200 11 9600
6 300 12 19200
CNC alarm messages of the Series 15i
No. Message Description
SR1040 Device open error (Remote DGN.) An error occurred when an input/output device for remote diagnosis
was opened.
SR1041 Illegal command (Remote DGN.) An invalid command was issued to an input/output device for remote
diagnosis.
SR1042 Data input error (Remote DGN.) An error occurred when data was entered into an input/output device
for remote diagnosis.
SR1043 Data output error (Remote DGN.) An error occurred when data was output from an input/output device for
remote diagnosis.
