6.2 OPERATIONS USING MDI KEYS
The MDI keys can be manipulated in the same way as those on the actual CNC.
Note, however, that for operations that require simultaneous clicking of two keys (referred to
as combined-key operations in the remainder of this manual), the keys need to be manipulated
differently.
Combined-key operation:
Through mouse manipulation on the personal computer, you cannot click two keys at the
same time.
Consequently, a combined-key operation requires the use of the Special key.
The procedure is as follows:
- Click the Special key.
- Then, click the keys to be clicked simultaneously in succession.
- You may click the keys in either order.
- As soon as you click the second key, the corresponding function will be
executed.
The usable key operations are as follows:
• CAN + RESET (Remove Parameter write enable alarm)
• SHIFT+ PAGE (Select Next Path screen)
• SHIFT+ HELP (Select loader Path screen)
• SHIFT+ → or SHIFT+ ← (Select editing program in background editor)
REMARKS
• The Special key does not exist on the actual CNC.
• If the clicked two keys are not those of any valid combined-key
operation, no operation will be performed.
