FANUC CNC Simulator for PC, Operator's Manual Additional Manual Page 7

Additional Manual
Edit
App
rvDesi
g
.
7
/
41
Date
Design
Descri
p
tion
Data
FANUC CNC Simulator for PC
Oprator’s Manual
A
-90000E/01
Feb.01.2005
Page
Title
Draw
No.
H.Yamada
4 INSTALLATION AND UN-INSTALLATION
This chapter explains how to install the CNC Simulator and its attached programs in your
personal computer, as well as how to uninstall them from it.
Installation does not require the supplied USB protect key.
Installation procedure
Because this product requires Microsoft .NET Framework1.1 (SP1) (referred to as .NET
Framework in the remainder of this manual), the .NET Framework installer starts first.
If your personal computer already has .NET Framework installed, this installer does not start.
If so, go to step "5."
After .NET Framework has been installed, the CNC Simulator installer starts next.
1. Insert the CD-ROM into the CD drive.
In a while, the Microsoft .NET Framework1.1 installer automatically starts. After it has
started, proceed with the following steps:
2. The "License Agreement" window automatically starts up; select "Agree" and click Install
(I).
