B-70265EN/02 APPENDIX E.PARAMTER LIST
- 291 -
15246 Pressure control integration gain
[Data type] Word
[Unit of data]
[Valid data range] 0 to 32767
This is feedback integration gain for gas pressure control.
15247 Pressure control integral element preset value
[Data type] Word
[Unit of data]
[Valid data range] -32768 to 32767
Integral element preset value for gas pressure control
15248 Allowable gas pressure insufficiency
[Data type] Word
[Unit of data] (1=13Pa)
[Valid data range] 0 to 32767
Allowable value used to determine to issue no alarm if the gas
pressure does not reach the setting
15249 Gas pressure rising time
[Data type] Word
[Unit of data] sec
[Valid data range] 0 to 60
Set the gas pressure rising time in sequence 27.
15250 Gas pressure rising time 2
[Data type] Word
[Unit of data] sec
[Valid data range] 0 to 45
Set a time required to proceed, in sequence 18, from the negative
pressure in exhaust completion (parameter No. 15240) to the intra-
tube pressure in discharge start (parameter No. 15241).
15255 RUN ON evacuation time
[Data type] Word
[Unit of data] sec
[Valid data range] 0 to 32767
Set an evacuation time to be applied at oscillator start time (RUN).
