B-70265EN/02 4.MAINTENANCE
- 67 -
Maintenance parts [Nonrepairable parts]
Q'ty
Name Specification
C1000-E C2000-E C4000-E C5000-E C6000-E
101 A70L-0001-0064#10 0 0 0 1 1
102 A97L-0201-0771#H-0.5-B 1 0 0 1 1
103 A97L-0200-0649#2-2-S 0 1 1 0 0
104
Gas filter
A97L-0200-0649#2-0.5-S 0 1 1 0 0
105 Nylon ferrule 1/4” A98L-0004-0348#2-N 6 16 18 4 4
106 Nylon ferrule 3/8” A98L-0004-0348#3-N 6 4 4 6 6
107 Nylon ferrule 1/2” A98L-0004-0348#4-N 2 4 4 4 4
108 A290-4514-X206 1 0 0 0 0
109
Shutter mirror
A290-4516-X204 0 1 1 1 1
110
Shutter mirror (for
guide laser)
A98L-0001-0708 1 1 1 1 1
111 A97L-0201-0968 1 0 0 0 0
112 A97L-0201-0556#B 0 1 0 0 0
113 A97L-0201-0439#B 0 0 1 0 0
114
Heat exchanger (out)
A97L-0201-0691#B 0 0 0 2 2
115 A97L-0201-0969 1 0 0 0 0
116 A97L-0201-0828 0 1 0 0 0
117 A97L-0201-0691#B 0 0 1 0 0
118
Heat exchanger (in)
A97L-0201-0439#B 0 0 0 2 2
119 A97L-0200-0849 2 2 4 7 10
120
Heat exchanger (for
use within the cabinet)
A97L-0201-0588 0 2 4 0 2
121 A97L-0200-0937#C 1 0 0 0 0
122 A290-4522-V200 0 1 0 0 0
123 A97L-0201-0972 0 0 1 0 0
124 A97L-0203-0206#B 0 0 0 1 0
125
Beam absorber
A97L-0203-0206#A 0 0 0 0 1
126 Warning lamp A04B-0815-C324 1 1 1 1 1
127 RF FET PCB1 A20B-1007-0140 1 2 4 4 6
128 RF FET PCB2 A20B-1007-0150 1 2 4 4 6
129
Step-up transformer
PCB (for power supply
B211)
A20B-1008-0150 1 2 4 4 6
130 A50L-2001-0342 1 2 4 4 6
131
Diode module (for
power supply B211)
A50L-2001-0439 8 16 32 32 48
132
Cooling fan (for power
supply B211)
A90L-0001-0396 2 4 8 8 12
133
Cooling fan (for
matching box)
A90L-0001-0396 1 2 4 0 0
134
Cooling fan (for
matching box)
A90L-0001-0396#T 0 0 0 4 6
