B-70265EN/02 APPENDIXG.INSTALLING GAS FITTINGS AND WATER FITTINGS
- 317 -
Water fittings (Material: Brass)
Tube
diameter
Screw
section
Ordering information
1/8” A97L-0200-0651#N-06A-B6mm
1/4” A97L-0200-0651#N-06B-B
1/4” A97L-0200-0651#N-08B-B8mm
3/8” A97L-0200-0651#N-08C-B
1/4” A97L-0200-0651#N-10B-B
3/8” A97L-0200-0651#N-10C-B
10mm
1/2” A97L-0200-0651#N-10D-B
3/8” A97L-0200-0651#N-12C-B12mm
1/2” A97L-0200-0651#N-12D-B
Nipple
16mm 1/2” A97L-0201-0554#N-16D-B
1/8” A97L-0200-0651#L-06A-B6mm
1/4” A97L-0200-0651#L-06B-B
1/4” A97L-0200-0651#L-08B-B8mm
3/8” A97L-0200-0651#L-08C-B
1/4” A97L-0200-0651#L-10B-B
3/8” A97L-0200-0651#L-10C-B
10mm
1/2” A97L-0200-0651#L-10D-B
3/8” A97L-0200-0651#L-12C-B12mm
1/2” A97L-0200-0651#L-12D-B
Elbow
16mm 1/2” A97L-0201-0554#L-16D-B
6mm - A97L-0200-0651#S-06
8mm - A97L-0200-0651#S-08
10mm - A97L-0200-0651#S-10
12mm - A97L-0200-0651#S-12
Sleeve
16mm - A97L-0201-0554#S-16
6mm - A97L-0200-0651#UN-06-B
8mm - A97L-0200-0651#UN-08-B
10mm - A97L-0200-0651#UN-10-B
12mm - A97L-0200-0651#UN-12-B
Box nut
16mm - A97L-0201-0554#UN-16-B
Water tube
Diameter Color Material
Ordering information
(x: Specifies a length not longer than
10 m in steps of 1 m.)
White Nylon A98L-0004-0263#8-W-x6mm
Black Nylon A98L-0004-0263#8-BA-x
White Nylon A98L-0004-0263#3-W-x8mm
Black Nylon A98L-0004-0263#3-BA-x
White Nylon A98L-0004-0263#4-W-x10mm
Black Nylon A98L-0004-0263#4-BA-x
White Nylon A98L-0004-0263#5-W-x12mm
Black Nylon A98L-0004-0263#5-BA-x
White Nylon A98L-0004-0263#6A-W-x16mm
Black Nylon A98L-0004-0263#6A-BA-x
Previous page
Next page
