Manual for Synchronous Spindle Motor Drive Additional Manual Page 2

Additional Manual
2
Manual for
Synchronous Spindle Motor Drive
EDT. DATE DESIG. DESCRIPTION PAGE /29
A-63639E-103 /03
NO.
TITLE
NEWLY Y.Toyozawa
K.Takahashi
2003.06.13 01
02 2003.10.15 K.Takahashi
A
dded SSM etc. Y.Toyozawa
03 2004.06.09 K.Takahashi Revised Pole detect, etc. Y.Toyozawa
1. Outline
1.1 System configuration
This manual describes the synchronous spindle motor drive based on the assumption of following configuration.
[Without SSM]
[With SSM]
(1) If your motor drive is different from this configuration, take care whether it is matter or not.
(2) The motor sensor should be equivalent to BZi / CZi sensor, that is sinusoidal signals A/B phase of 1Vpp.
(3) The three following function are not available for Synchronous spindle motor at this time.
Spindle switching control.
Speed range switching function
Unexpected disturbance torque detection function.
1.2 Applicable SPM
The following SPM are applied for driving Synchronous Spindle motor. If CNC is 30i, spindle software 9D70
(#H570) must be mounted on SPM.
(1) In case of αi series SPM without SSM
SPM Type-A, B: A06B-611x-Hxxx#H553 (or #H570) ; 200V line
SPM Type-A, B: A06B-612x-Hxxx#H553 (or #H570) ; 400V line
Spindle software 9D53, 9D70
(2) In case of αi series SPM with SSM
SPM Type-B: A06B-6112-Hxxx#H553 (or #H570) ; 200V line
SPM Type-B: A06B-6122-Hxxx#H553 (or #H570) ; 400V line
Spindle software 9D53/B (or later), 9D70/A (or later)
Feedback cable
Spindle
BZi / CZi
sensor
Synchronous
spindle motor
CNC
Terminal for power cable
SSM
(Sub Module for
Synchronous Spindle
SPM JYA2
Type-B
JYA4
TB2
or
CZ2
Spindle software
9D53/B (or later) is
required.
CX31
Feedback cable
Spindle
BZi / CZi
sensor
Synchronous
spindle motor
CNC
SPM JYA2
Type-A
or
Type-B TB2
or
CZ2
Caution
For the protection to SPM and spindle motor, you must consider about the item and paramete
r
with mark and it should be execute correctly.
Unless these points, the protection to SPM and spindle motor may be lost and it causes the
broken of SPM or spindle motor.
Caution
！
