Manual for Synchronous Spindle Motor Drive Additional Manual Page 7

Additional Manual
7
Manual for
Synchronous Spindle Motor Drive
EDT. DATE DESIG. DESCRIPTION PAGE /29
A-63639E-103 /03
NO.
TITLE
NEWLY Y.Toyozawa
K.Takahashi
2003.06.13 01
02 2003.10.15 K.Takahashi
A
dded SSM etc. Y.Toyozawa
03 2004.06.09 K.Takahashi Revised Pole detect, etc. Y.Toyozawa
15i 16i 30i
3118 4118 4118 Not used (Set this parameter to “0”.)
15i 16i 30i
3119 4119 4119 Interference voltage compensation
15i 16i 30i
3120 4120 4120 Dead time compensation data
15i 16i 30i
3124 4124 4124 Not used (Set this parameter to “0”.)
15i 16i 30i
3127 4127 4127 Setting for Load Meter display on CNC screen
15i 16i 30i
3128 4128 4128 Not used (Set this parameter to “0”.)
15i 16i 30i
3130 4130 4130 Not used (Set this parameter to “0”.)
15i 16i 30i
3150 4150 4150 Not used (Set this parameter to “0”.)
15i 16i 30i
3155 4155 4155 Not used (Set this parameter to “0”.)
15i 16i 30i
3158 4158 4158 Not used (Set this parameter to “0”.)
15i 16i 30i
3161 4161 4161 Not used (Set this parameter to “0”.)
15i 16i 30i
3368 4368 4368 Pole pair of motor
15i 16i 30i
#7 #6 #5 #4 #3 #2 #1 #0
3398 4398 4398 SELMET
SELMET: The selection of pole detection mode (9D53/C, 9D70/B or later)
=”0”: DC current mode is used
=”1”: Auto mode (Minute moving mode + Stop state mode) is used
This parameter must be set “0” if the software except the above is used. Please refer to chapter 7 (Pole
position detection function) about this parameter.
15i 16i 30i 5
th
4
th
3
rd
2
nd
1
st
(9D53/C, 9D70/B or later)
3449 4449 4449 5
th
, 4
th
, 3
rd
digit: Current value B for Stop state mode of pole detection (unit: %)
2
nd
, 1
st
digit: Current value C for Stop state mode of pole detection (unit: %)
When Stop state mode is executed at Auto mode of pole detection, this parameter is used.
This parameter must be set “0” if the software except the above is used. Please refer to chapter 7 (Pole
position detection function) about this parameter.
