Manual for Synchronous Spindle Motor Drive Additional Manual Page 5

Additional Manual
5
Manual for
Synchronous Spindle Motor Drive
EDT. DATE DESIG. DESCRIPTION PAGE /29
A-63639E-103 /03
NO.
TITLE
NEWLY Y.Toyozawa
K.Takahashi
2003.06.13 01
02 2003.10.15 K.Takahashi
A
dded SSM etc. Y.Toyozawa
03 2004.06.09 K.Takahashi Revised Pole detect, etc. Y.Toyozawa
POLE2.POLE1: These bits decide the pole number of the motor
00: 2 poles 01: 4 poles 10: 8 poles 11: 6 poles
15i 16i 30i
#7 #6 #5 #4 #3 #2 #1 #0
3012 4012 4012 PWM2 PWM1
PWM2, PWM1: PWM carrier frequency
15i 16i 30i
#7 #6 #5 #4 #3 #2 #1 #0
3013 4013 4013 DS5 DS4 DS3 DS2 DS1
DS5, DS4, DS3, DS2, DS1: Set DS5-1 to the suitable value for used SPM.
15i 16i 30i
3020 4020 4020 Motor Maximum speed (unit: min
-1
)
If SSM doesn’t use, it is necessary to limit this parameter.
Please refer to chapter 6 (Sub Module for Synchronous Spindle Motor) about the detail.
15i 16i 30i
3024 4024 4024 Speed zero detecting level (unit: 0.01%)
Speed zero level is limited to 200min
-1
. (9D53/B or later, 9D70)
(Speed zero level) = Minimum [200 min
-1
, (No.4020: Motor Maximum speed) * No.4024]
15i 16i 30i
3080 4080 4080 Limit of regenerative power (unit %)
15i 16i 30i
5
th
4
th
3
rd
2
nd
1
st
3083 4083 4083 5
th
digit: =0(Normal setting) / =1(setting for the current step mode)
4
th
, 3
rd
digit: Current ratio (unit %) at the pole-detection sequence
2
nd
, 1
st
digit: Time to confirm motor stop (unit 0.1sec) at the pole-detection sequence
Please refer to chapter 7 (Pole position detection function) about this parameter.
15i 16i 30i
3084 4084 4084 AMR offset (0 to 8192) (9D53/C, 9D70/B or later)
This is the compensation parameter for AMR offset function. This parameter must be set “0” if the software
except the above is used.
Please refer to chapter 7 (Pole position detection function) about this parameter.
15i 16i 30i
3085 4085 4085 Excitation phase shift (9D53/C, 9D70/B or later)
This parameter shifts the excitation phase of the motor to make a fine adjustment to AMR offset. This
parameter must be set “0” if the software except the above is used.
Please refer to chapter 7 (Pole position detection function) about this parameter.
15i 16i 30i
3086 4086 4086 Inductance ratio (unit 0.1%) (9D53/B or later, 9D70)
This parameter must be set “0” if the software except the above is used.
15i 16i 30i
3087 4087 4087 Over speed level (unit %)
Over speed level is limited to 115%. (9D53/B or later, 9D70)
(Over speed level) = (No.4020: Motor maximum speed) * Minimum [115%, No.4087]
Caution
！
